Specifications
Property | Value |
---|---|
SKU | PTPRO700FC-REF |
App Connectivity | No |
Boiler Configuration | Independent Steam and Brew |
Number of Boilers | 2 |
Boiler Features | Brew & Steam Simultaneously,Rapid Steam |
Brew Boiler Auto-Fill | Yes |
Brew Boiler Heater Location | Internal |
Brew Boiler Insulation | Yes |
Brew Boiler Material | Stainless Steel |
Brew Boiler Orientation | Vertical |
Brew Boiler Volume (Oz) | 25 fl-oz |
Brew Group Features | Adjustable Flow Rate |
Three-Way Valve | Manual |
Back Flush Capable | Yes |
Brew Group Material | Chrome Plated Brass |
Brew Group Size (mm) | 58 mm |
Brew Group Type | E61 |
Brew Boiler Wattage | 1200 |
Recommended Application | Home / Residential |
NSF Certified | No |
Display Type | PID Control Screen |
Controls and Additional Features | Aroma / Flow Control,Brew Temperature Display,Clock / Timer,Low-Water Warning,Power Light,Pre-Infusion,Steam Control,Temperature Control |
Pressure Gauges | Brew Circuit,Brew Head,Steam Boiler |
Type of Controls | Lever,PID |
Cup Height (max, inches) | 4 in |
Cup Warmer Material | Stainless Steel |
Cup Warmer Size (L-in x W-in) | 10 x 8 |
Cup Warmer | Passively Heated |
Drain Line Adaptable (Plumbable) | Yes |
Drip Tray Capacity (oz) | 32 fl-oz |
Drip Tray Cover Material | Stainless Steel |
Drip Tray Material | Stainless Steel |
Portafilter Baskets Included | Double,Single |
Frame Material | Steel |
Housing Color | Stainless Steel |
Housing Material | Stainless Steel |
Foot/Leg Height (inches) | 1.35 in |
Depth (Inches) | 18.7 in |
Height (Inches) | 16.5 in |
Weight (Lbs) | 68.4 lbs |
Width (Inches) | 13.4 in |
Bottomless Portafilter Available | Yes |
Property | Value |
---|---|
Filter Diameter (mm) | 58 mm |
Portafilter Handle Material | Plastic |
Portafilter Material | Chrome Plated Brass |
Number of Portafilters Included | 2 |
Ground, E.S.E., Pod and Capsule Compatibility | Ground Coffee |
Portafilter Type | Commercial Style |
Portafilter Weight (lbs) | 1.2 lbs |
Portafilter Diameter | 58 mm |
Adjustable Brew Pressure | Yes |
Pump Pressure (Max. Bar) | 16 Bar |
Pump Type | Rotary Pump |
Pump Wattage | 120 watts |
Warranty Service Provider Email | support@wholelattelove.com |
Warranty Service Provider | Whole Latte Love |
Warranty Service Provider Phone Number | 888-411-5282 |
Manufacturers Warranty Period | 3 |
Amps | 11.6 A |
Volt | 110V-120V (US) |
Watts | 1400 Watt |
Power Cord Length (inches) | 48 in |
Power Cord Storage | No |
Steam Boiler Auto-Fill | Yes |
Steam Boiler Heater Location | Internal |
Steam Boiler Insulation | Yes |
Steam Boiler Material | Stainless Steel |
Steam Boiler Orientation | Vertical |
Steam Boiler Type | Large Volume |
Steam Boiler Volume (Oz) | 67.6 fl-oz |
Steam Boiler Vacuum Relief Valve | Yes |
Steam Boiler Wattage | 1400 Watt |
Steam Wand Features | Insulated Grip,No-Burn,Swappable Steam Tips |
Steam Tip Hole Count | 4 |
Steam Wand Material | Stainless Steel |
Steam Wand Movement Type | Fully Articulated |
Steam Wand | Commercial Style |
Water Reservoir Access Location | Top |
Water Reservoir Capacity | 101.4 fl-oz |
Water Reservoir Features | Removable |
Water Filter Included | No |
Water Source | Reservoir and Water Line |
Maximum Incoming Water Pressure (PSI) | 29 PSI |
